LORRIC【FU-LT Series】
Lite Flow Clamp-On Ultrasonic Flow Meter
Description
Made in Taiwan, the FU-LT series clamp-on ultrasonic flowmeters are designed for small-diameter pipes below 1 inch. Using a non-contact measurement principle, they require no pipe cutting, no coupling gel, no pressure loss, and do not contaminate the fluid, making them suitable for various chemical fluids and harsh environments.
| Applicable Pipe Size | 1/4″ ~ 1″ (DN8 ~ DN25) |
| Fluid Temperature | 0 ~ 85°C (No ice on pipe surface) |
| Applicable Fluids | Various liquids (no impurities or bubbles) |
| Measurement Accuracy |
±3.0% of reading (10% ~ 100% F.S.) ±0.3% F.S. (0% ~ 10% F.S.) |
| Protection Rating | IP66 |
| Power Supply | DC 24V |
| Display Module | Three-color backlight + 3-line, 16-character LCD |
| Input / Output |
Analog output (self-powered 10-bit 4–20mA) Modbus RTU RS485 NPN output |
| Certifications | CE Certificate |
